Type

Unit

YZC7

Working mass

kg

7160

Axle load, front drum

kg

3630

Axle load, rear drum

kg

3530

Static linear load, front drum

N/cm

247

Static linear load, rear drum

N/cm

240

Speed range

km/h

0-10.5

Theoretical gradeability

%

33

Min. Outer turning radius

mm

4800

Min. Clearance

mm

260

Steering angle

±38°

Oscillating angle

±11°

Oscillating angle frequency

Hz

48

Nominal amplitude (High/Low)

mm

0.71/0.35

Centrifugal force @48Hz High/Low amplitude

kN

71/35

Vibrating drum diameter

mm

1040

Vibrating drum width

mm

1450

Engine

Deutz

Rated power @2000r/min

kW

51

Overall dimensions(L*W*H)

mm

4545*1600*3090

Fuel tank capacity

L

140

Water tank capacity

L

2*325
