  |→　Road building machinery → Roller → Vibratory Compactor → Double drum

XD111
Requset a Quote



Type

Unit

XD111

Working mass

kg

10900

Axle load, front drum

kg

5500

Axle load, rear drum

kg

5400

Static linear load, front drum

N/cm

284

Static linear load, rear drum

N/cm

279

Speed range

km/h

0-10

Theoretical gradeability

%

30

Min. Outer turning radius

mm

2900

Min. Clearance

mm

420

Steering angle

±(23° +23°)

Crab-walking angel

±23°

Swinging angle

±12°

Max. crab-walking distance

mm

±200

Oscillating angle frequency

Hz

30-48

Nominal amplitude (High/Low)

mm

0.80/0.41

Centrifugal force @48Hz High/Low amplitude

kN

133/66

Vibrating drum diameter

mm

1250

Vibrating drum width

mm

1900

Engine

Cummins

Overall dimensions(L*W*H)

mm

6000*2030*3320

Fuel tank capacity

L

220

Water tank capacity

L

2*450

XD111：
Option parts：（drum with ten-gear amplitude）
（add 150mm to the overall height）
（drive’s cab and ROPS, add 150mm to the overall height）

Note: All specifications on our website are subject to technical modifications without notice.
