Type

Unit

Specifications

Working mass

kg

12000

Distributed weight on front drum

kg

6700

Static linear load

N/cm

308

Speed range

Km/h

0-10.4

Theoretical gradeability

%

45

Min. turning radius

mm

6800

Steering angle

°

±30

Oscillating angle

°

±10

Vibration frequency(L/H)

Hz

30/35

Nominal working amplitude (H/L)

mm

1.80/0.9

Centrifugal force(H/L)

Kn

290/180

Drum diameter

mm

1523

Drum width

mm

2130

Vibrating drum diameter

mm

1520

Engine

Cummins

Overall dimensions(L*W*H)

mm

5970*2300*2970
