Item

Unit

Parameter

1

Max. speed

km

90

2

Min. turning diameter

m

18.4

3

Brake distance

m

≤7

4

Approach angle

°

21

5

Departure angle

°

12

6

Chassis model

VOLVO FM12/6×4

7

Front track

mm

2029

8

Rear track

mm

1872

9

Total vehicle weight

kg

32600

10

Engine model

D12

11

Max. Engine power

kW/rpm

279/1700～1800

14

Max. Engine torque

N.m/rpm

1850/1100～1300

15

Max. grade-ability

%

38

16

Fuel consumption limit

L/100km

40

17

Outlinedimensions (Length′ Width ′Height)

mm

11100×2500×3990

Item

Unit

Parameter

1

Theoretical output

m3/h

70/140

2

Max. delivery pressure

MPa

11.8/6.38

3

Reach height

m

39.8

4

Reach depth

m

27.9

5

Front outrigger transverse span

mm

8350

6

Rear outrigger transverse span

mm

7200

7

Outrigger longitudinal span

mm

7800

8

Placing boom slewing range

°

370
