Description

specification

unit

Bucket capacity

3.5

m3

Rated load

6000

kg

Dump clearance

3100

mm

Dump reach

1250

mm

Raising time

6.5

s

Total cycling time

12

s

Max.traction force

165

kN

Max.breakout force

196

kN

Articulation angle

35

°

Min.turning radius

6495

mm

Gradeability

28

°

Wheel base

3400

mm

Track

2200

mm

Speed

,

,

1st(F/R)

6/6

km/h

2nd(F/R)

11/11

km/h

3rd(F)

23/23

km/h

4th(F)

36

km/h

Engine Model

C6121ZG10

,

Rated Power/Rated Speed

174/2200

kw/ r/min

Displacement

10.46

L

Rated Fuel Consumption

≤240

g/Kw.h

Max. torque/ Speed

912/1400

N.m/ r/min

Transmission Model

ZF4WG-200

Travel Speed

1st (F/R)

6.0/6.0

Km/h

2nd (F/R)

11.0/11.0

Km/h

3rd (F/R)

22/22

Km/h

4th (F)

35.0

Km/h

Axle

Front

Meritor

Rear

Meritor

Dimension (L*W*H)

8593*3050*3534

mm

Operating weight

20.5

t

Tyres

23.5-25-16PR

,
