Item

Specification

Unit

Operation Weight

15075

kg

Standard Bucket Capacity

0.6

m3

Arm Length

2500

mm

Engine

Model

4D34TL

Type

Turbo-charged with inter-cooled

Power

86.5/2200

kw/rpm

Max. Torque

420N.m at 1600 rpm

No. of cylinder

4

Displacement

3.91

L

Hydraulic System

Main Pump

Type

Variable displacement axial piston pumps

Max. Displacement

2*63

c m3/r

Working Pressure

30

Mpa

Hydraulic Motor

Slew

Fixed displacement axial piston motor

Travel

Variable displacement axial piston motor

Performance

Slew Speed

13.6

rpm

Min. Back Slew Radius

2468

mm

Max. Travel Speed High/Low

33.2/6.2

Km/h

Gradeability

33.7

°

Tractive Effort

85.015

kN

Max. Digging Force of Bucket

85

kN

Max. Digging Force of Arm

67

kN

Tank Capacity

Fuel Tank Capacity

217

L

Hydraulic Tank Capacity

217

L

Max. Digging Reach

8258

mm

Max. Digging Reach on Ground

8054

mm

Max. Digging Depth

5640

mm

Max. Vertical Wall Digging Depth

4194

mm

Max. Cutting Height

8666

mm

Max. Dumping Height

6296

mm

Min. Front Slew Radius

2475

mm

Dimension (L*W*H)

7825*3589*3528

mm
