QY40K FULL HYDRAULIC TRUCK CRANE
Self-made special truck crane chassis, powerful and environmental engine with output 266 kW2200 rpm and torque 1460N.m/1400 rpm, greatly improve overall travel performance.
Excellent performance. The product fills the gap of 40t class truck crane in the domestic market. The lifting and traveling performance is in the lead of domestic similar products and also in the world advanced level. Larger outrigger span, good operation stability and 360°full swing,2-section lattice jib with 3 kinds of offset angle and single top crease crane operation application.
Same type of main and auxiliary winch use drum built-in planetary gear reducer,? hoisting speed can be regulated in proportion by variable displacement motor to realize various speed such as low speed for heavy duty and high speed for light duty to increase working efficiency.
Swing system with free sliding function uses planetary gear reducer and constant closed brake, and drive spur gear type slewing ring by motor. Swing system is fitted with a buffer valve to realize free sliding and fine motion control.
Five-section ovoid telescopic boom, two-section side-mounted jib, single cylinder front supported for elevating, fully hydraulic control and double ’H’-shaped outriggers.
Well-equipped safety protection device such as automatic load moment limiter, overload and over-winding cutout device increase the safety for crane operation.
Adoption of hydraulic pilot control technology, two joystick handles realize all control movements on crane superstructure and improve crane fine motion control and operating comfortableness. Control components are integrated modular designed for the little energy loss and high efficiency. High accurate hard pipe and ferrule-type compression joint improve the cleaning in hydraulic system and avoid leakage so as so ensure high reliability for hydraulic system.
Advanced and reliable manufacture technology of NC laser and plasma cutting. NC machining center and first class general assembly line guarantee the overall machine conformability and reliability.
Ergonomically designed two cabs are accord with ISO standard, and air-conditioner in crane superstructure and carrier. The driver’s cab is luxury full-width cab, spacious and comfortable, equipped with shock-absorption adjustable seat for reducing harmful shake and easing driver’s tiredness. The operator’s cab is mounted at right side, all-round streamlined shape, and equipped with LC display monitor for a clear glance of all operation.
QY40K plateau type is available for selection of customers in plateau area, is suitable for operation in high altitude land with special working environment of heavy wind and sand, lower temperature, rare air and strong ultra-violet.
Main Technical Specifications
Technical Data for Lifting Operation
|
Classificatory |
Item |
Parameter |
|
XZJ5401JQZ40K |
XZJ5403JQZ40K |
|
Outline dimension |
Overall length mm |
13050 |
|
Overall width mm |
≤2750 |
≤2800 |
|
Overall height mm |
3430 |
|
Wheel base |
Axle1,Axle2 mm |
1520 |
|
Axle 2, Axle 3 mm |
3815 |
|
Axle 3, Axle 4 mm |
1350 |
|
Tread |
Front-wheel mm |
2240 |
2240 |
|
Trailing-wheel mm |
2055 |
2075 |
|
Mass |
Total mass in travel state kg |
39800 |
40400 |
|
Axle load |
Front axle kg |
13900 |
14500 |
|
Rear axle kg |
25900 |
25900 |
|
Power |
Model |
WD615.46 |
WD615.334 |
|
Engine rated output kW/(r/min) |
266/2200 |
247/2200 |
|
Engine rated torque N.m/(r/min) |
1460/1400 |
1350/1400 |
|
Engine rated speed r/min |
2200 |
2200 |
|
Travel performance |
Travel speed |
Max. travel speed km/h |
≥75 |
|
Min. stable travel speed km/h |
4.3 |
|
Turning diameter |
Min. turning diameter mm |
≤24000 |
|
Min. turning diameter at boom tip mm |
≤26800 |
|
Min. ground clearance mm |
≥285 |
|
Approach angle |
≥16° |
|
Departure angle |
≥11° |
|
Braking distance (at 30km/h with full load) m |
≤10 |
|
Max. grade-ability % |
≥46% |
|
Fuel consumption for 100km L |
≤46 |
Main Technical Data for Lifting Operation
|
Classificatory |
Item |
Unit |
Parameter |
|
Lifting performance |
Max. total rated lifting capacity |
t |
40 |
|
Min. rated working radius |
m |
3 |
|
Turning radius at turntable tail |
m |
≤3.482 |
|
Max. load moment |
Base boom |
kN.m |
1400 |
|
Fully extended boom |
kN.m |
720 |
|
Fully extended boom + Jib |
kN.m |
528 |
|
Outrigger span |
Longitudinal |
m |
5.65 |
|
Lateral |
m |
6.6 |
|
Lifting height |
Base boom |
m |
10.9 |
|
Fully extended boom |
m |
40.4 |
|
Fully extended boom + Jib |
m |
55.1 |
|
Working speed |
Boom raising time |
s |
88 |
|
Boom full extension time |
s |
180 |
|
Max. swing speed |
r/min |
2.0 |
|
Hoist speed |
Main winch |
m/min |
≥110 |
|
Aux. winch |
m/min |
≥110 |
|
Noise limit |
Crane exterior noise |
dB (A) |
≤118 |
|
At seated position |
dB (A) |
≤90 |
